3M 9297 Series
64 variants · 3M
About the 3M 9297 Series
The 3M 9297 Series series groups 64 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common connector type of Header, Breakaway, contact length - mating of 0.318\" (8.08mm) and contact material of Copper Alloy. Variants differ by contact finish - mating, contact finish thickness - mating and contact length - post, so you can match the exact contact finish - mating your application requires using the selection guide below.
Select a variant by
- Contact finish - mating
- Gold · Tin · Tin-Lead
- Contact finish thickness - mating
- 10.0µin (0.25µm) · 100.0µin (2.54µm) · 200.0µin (5.08µm)
- Contact length - post
- 0.110\" (2.79mm) · 0.125\" (3.18mm) · 0.310\" (7.87mm)
- Insulation material
- Polybutylene Terephthalate (PBT), Polyester, Glass Filled · Polycyclohexylenedimethylene Terephthalate (PCT)
- Overall contact length
- 0.528\" (13.42mm) · 0.543\" (13.80mm) · 0.728\" (18.49mm)
- Positions
- 3 · 6 · 36
- Contact finish - post
- Gold · Tin
Shared specifications
- Connector type
- Header, Breakaway
- Contact length - mating
- 0.318\" (8.08mm)
- Contact material
- Copper Alloy
- Contact shape
- Square
- Current rating
- 2.5A
- Fastening type
- Push-Pull
- Gender
- Male Pin
- Insulation color
- Black
- Insulation height
- 0.100\" (2.54mm)
- Material flammability rating
- UL94 V-0
- Mounting type
- Through Hole
- Operating temperature
- -40°C ~ 105°C
Variant comparison
| Parameter | 929700-01-03-RK | 929700-01-06 | 929700-01-06-RK | 929700-01-36 | 929700-01-36-RK | 929700-08-36-RK |
|---|---|---|---|---|---|---|
| Contact finish - mating | Tin | Tin-Lead | Tin | Tin-Lead | Tin | Tin |
| Contact finish thickness - mating | 200.0µin (5.08µm) | 100.0µin (2.54µm) | 200.0µin (5.08µm) | 100.0µin (2.54µm) | 200.0µin (5.08µm) | 200.0µin (5.08µm) |
| Contact length - post | 0.110\" (2.79mm) | 0.110\" (2.79mm) | 0.110\" (2.79mm) | 0.110\" (2.79mm) | 0.110\" (2.79mm) | 0.310\" (7.87mm) |
| Insulation material | Polycyclohexylenedimethylene Terephthalate (PCT) | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Polycyclohexylenedimethylene Terephthalate (PCT) | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Polycyclohexylenedimethylene Terephthalate (PCT) | Polycyclohexylenedimethylene Terephthalate (PCT) |
| Overall contact length | 0.528\" (13.42mm) | 0.528\" (13.42mm) | 0.528\" (13.42mm) | 0.528\" (13.42mm) | 0.528\" (13.42mm) | 0.728\" (18.49mm) |
| Positions | 3 | 6 | 6 | 36 | 36 | 36 |
| Contact finish - post | Tin | — | Tin | — | Tin | Tin |
