MP2-S024-41M1-C-LR
3M
24Tube4
Ref. price$6.06
Lead time on requestGet quote ›
3M MP2S Series
3 variants · 3M
About the 3M MP2S Series
The 3M MP2S Series series groups 3 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common color of Beige, connector type of Receptacle, Female Sockets and connector usage of Backplane. Variants differ by contact finish thickness, package and positions, so you can match the exact contact finish thickness your application requires using the selection guide below. All listed 3M MP2S Series part numbers are active and orderable.
Select a variant by
- Contact finish thickness
- 3.00µin (0.076µm) · 30.0µin (0.76µm)
- Package
- Bulk · Tube
- Positions
- 24 · 30
- Rows
- 4 · 5
Shared specifications
- Color
- Beige
- Connector type
- Receptacle, Female Sockets
- Connector usage
- Backplane
- Contact finish
- Gold
- Current rating
- 1.5A
- Features
- Board Guide, Board Lock, Spacer
- Material flammability rating
- UL94 V-0
- Mounting type
- Board Edge, Through Hole, Right Angle
- Operating temperature
- -55°C ~ 125°C
- Pitch
- 0.079\" (2.00mm)
- Termination
- Solder
Variant comparison
| Parameter | MP2-S024-41M1-C-LR | MP2-S030-51M1-C-LR | MP2-S030G-51M1-C-KR |
|---|---|---|---|
| Contact finish thickness | 3.00µin (0.076µm) | 3.00µin (0.076µm) | 30.0µin (0.76µm) |
| Package | Tube | Tube | Bulk |
| Positions | 24 | 30 | 30 |
| Rows | 4 | 5 | 5 |
Request a quote on any 3M MP2S Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the 3M MP2S Series variants differ?
- 3M MP2S Series part numbers differ by contact finish thickness, package, positions and rows. Use the selection guide above to pick by contact finish thickness.
- How many 3M MP2S Series part numbers are listed?
- 3 3M MP2S Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for 3M MP2S Series?
- Request a quote (RFQ) for any 3M MP2S Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
