REB-A2A-BU
Adam Tech
Blue15 AFeed Through
Ref. price$1.12
Lead time on requestGet quote ›
Adam Tech REBA Series
9 variants · Adam Tech
About the Adam Tech REBA Series
The Adam Tech REBA Series series groups 9 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common package of Box. Variants differ by color, type and current - UL, so you can match the exact color your application requires using the selection guide below. All listed Adam Tech REBA Series part numbers are active and orderable.
Select a variant by
- Color
- Black · Blue · Gray · Green, Yellow
- Type
- End Plate · Feed Through
- Current - UL
- 15 A · 20 A · 50 A · 65 A
- Stripping length
- 8mm ~ 10mm · 12mm · 18mm
- Terminal - width
- 4.2mm · 5.2mm · 8.2mm · 10.2mm
- Voltage - UL
- 300V · 600V
- Wire gauge or range - AWG
- 6-24 AWG · 8-24 AWG · 12-26 AWG · 14-26 AWG
- Wire gauge or range - mm2
- 0.2-1.5mm² · 0.2-2.5mm² · 0.2-6mm² · 0.2-10mm²
Shared specifications
- Package
- Box
Variant comparison
| Parameter | REB-A2A-BU | REB-A2A-GY | REB-A2A-YG | REB-A2B-BU | REB-A2B-YG | REB-A2D-BU |
|---|---|---|---|---|---|---|
| Color | Blue | Gray | Green, Yellow | Blue | Green, Yellow | Blue |
| Type | Feed Through | Feed Through | Feed Through | Feed Through | Feed Through | Feed Through |
| Current - UL | 15 A | 15 A | 15 A | 20 A | 20 A | 50 A |
| Stripping length | 8mm ~ 10mm | 8mm ~ 10mm | 8mm ~ 10mm | 8mm ~ 10mm | 8mm ~ 10mm | 12mm |
| Terminal - width | 4.2mm | 4.2mm | 4.2mm | 5.2mm | 5.2mm | 8.2mm |
| Voltage - UL | 300V | 300V | 300V | 600V | 600V | 600V |
| Wire gauge or range - AWG | 14-26 AWG | 14-26 AWG | 14-26 AWG | 12-26 AWG | 12-26 AWG | 8-24 AWG |
| Wire gauge or range - mm2 | 0.2-1.5mm² | 0.2-1.5mm² | 0.2-1.5mm² | 0.2-2.5mm² | 0.2-2.5mm² | 0.2-6mm² |
Request a quote on any Adam Tech REBA Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Adam Tech REBA Series variants differ?
- Adam Tech REBA Series part numbers differ by color, type, current - UL and stripping length. Use the selection guide above to pick by color.
- How many Adam Tech REBA Series part numbers are listed?
- 9 Adam Tech REBA Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Adam Tech REBA Series?
- Request a quote (RFQ) for any Adam Tech REBA Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
