RF55-32D-T-00-50-A-SH
Adam Tech
Code DTrayRF
Ref. price$3.4600
Lead time on requestGet quote ›
Adam Tech RF55 Series
3 variants · Adam Tech
About the Adam Tech RF55 Series
The Adam Tech RF55 Series series groups 3 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common body material of Brass, center contact plating of Gold and frequency - max of 4 GHz. Variants differ by body finish, cable group and center contact material, so you can match the exact body finish your application requires using the selection guide below. All listed Adam Tech RF55 Series part numbers are active and orderable.
Select a variant by
- Body finish
- Nickel · Tin, Nickel
- Cable group
- - · RG-174, 316
- Center contact material
- Beryllium Copper · Phosphor Bronze
- Connector type
- Jack, Male Pin · Plug, Male Pin
- Contact termination
- Crimp · Solder
- Fastening type
- Latch Lock · Locking Ramp
- Features
- Code B · Code D · Code F
- Housing color
- Brown · Violet, Bordeaux · White
Shared specifications
- Body material
- Brass
- Center contact plating
- Gold
- Frequency - max
- 4 GHz
- Impedance
- 50 Ohms
- Includes
- -
- Ingress protection
- -
- Insertion loss
- -
- Mating cycles
- -
- Mounting feature
- -
- Number of ports
- 1
- Operating temperature
- -40°C ~ 85°C
Variant comparison
| Parameter | RF55-32D-T-00-50-A-SH | RF55-34B-T-02-50-SH | RF55-34F-T-02-50-SH |
|---|---|---|---|
| Body finish | Tin, Nickel | Nickel | Nickel |
| Cable group | - | RG-174, 316 | RG-174, 316 |
| Center contact material | Phosphor Bronze | Beryllium Copper | Beryllium Copper |
| Connector type | Plug, Male Pin | Jack, Male Pin | Jack, Male Pin |
| Contact termination | Solder | Crimp | Crimp |
| Fastening type | Locking Ramp | Latch Lock | Latch Lock |
| Features | Code D | Code B | Code F |
| Housing color | Violet, Bordeaux | White | Brown |
Request a quote on any Adam Tech RF55 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Adam Tech RF55 Series variants differ?
- Adam Tech RF55 Series part numbers differ by body finish, cable group, center contact material and connector type. Use the selection guide above to pick by body finish.
- How many Adam Tech RF55 Series part numbers are listed?
- 3 Adam Tech RF55 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Adam Tech RF55 Series?
- Request a quote (RFQ) for any Adam Tech RF55 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
