KL351100
American Electrical Inc.
DisconnectBeigeASK
Ref. price$4.01
Lead time on requestGet quote
American Electrical Inc. KL35 Series
2 variants · American Electrical Inc.
About the American Electrical Inc. KL35 Series
The American Electrical Inc. KL35 Series series groups 2 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common color of Beige, current - UL of 6.3 A and disconnect type of Fuse, Lever. Variants differ by fuse type, terminal - width and wire gauge or range - AWG, so you can match the exact fuse type your application requires using the selection guide below. All listed American Electrical Inc. KL35 Series part numbers are active and orderable.
Select a variant by
- Fuse type
- 1 1/4\" x 1/4\ · 5mm x 20mm, 5mm x 25mm
- Terminal - width
- 8.0mm · 10.0mm
- Wire gauge or range - AWG
- 8-22 AWG · 8-26 AWG
Shared specifications
- Color
- Beige
- Current - UL
- 6.3 A
- Disconnect type
- Fuse, Lever
- Material - insulation
- Polyamide (PA66), Nylon 6/6
- Material flammability rating
- UL94 V-2
- Number of levels
- 1
- Package
- Box
- Positions
- 2
- Stripping length
- 12mm
- Termination style
- Screw
- Type
- Disconnect
- Voltage - UL
- 600V
Variant comparison
| Parameter | KL351100 | KL351120 |
|---|---|---|
| Fuse type | 5mm x 20mm, 5mm x 25mm | 1 1/4\" x 1/4\ |
| Terminal - width | 8.0mm | 10.0mm |
| Wire gauge or range - AWG | 8-26 AWG | 8-22 AWG |
Request a quote on any American Electrical Inc. KL35 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
