65801-105
Amphenol
5IDC0.100\" (2.54mm)
Ref. price$1.0100
Lead time on requestGet quote
Amphenol 658011 Series
7 variants · Amphenol
About the Amphenol 658011 Series
IC Source Direct is a China connector distributor, supplier and independent procurement agent for Amphenol 658011 Series components, matching housing, contact and mating cycles across the Shenzhen interconnect channel. The Amphenol 658011 Series series groups 7 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common actuator material of -, connector (Contact type) of Receptacle and contact finish of Tin. Variants differ by actuator color, cable end type and features, so you can match the exact actuator color your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current Amphenol 658011 Series variants and discontinued ones from a single page.
Select a variant by
- Actuator color
- - · Black · Gray
- Cable end type
- - · Notched · Straight, Tapered
- Features
- - · Solder Retention, Zero Insertion Force (ZIF)
- FFC, FCB thickness
- 0.30mm, 0.33mm · 0.33mm
- Locking feature
- - · Slide Lock
- Positions
- 2 · 4 · 5 · 6 · 9
- Termination
- IDC · Solder
Shared specifications
- Actuator material
- -
- Connector (Contact type)
- Receptacle
- Contact finish
- Tin
- Contact finish thickness
- 100.0µin (2.54µm)
- Contact material
- Copper Nickel Alloy
- Current rating
- 2A
- Flat flex type
- CIC
- Height above board
- -
- Housing color
- Blue
- Housing material
- Thermoplastic
- Material flammability rating
- UL94 V-0
- Mating cycles
- 100
Variant comparison
| Parameter | 65801-102LF | 65801-104 | 65801-105 | 65801-106 | 65801-106LF | 65801-109 |
|---|---|---|---|---|---|---|
| Actuator color | Black | - | - | - | Gray | - |
| Cable end type | Straight, Tapered | - | - | - | Notched | - |
| Features | Solder Retention, Zero Insertion Force (ZIF) | - | - | - | Solder Retention, Zero Insertion Force (ZIF) | - |
| FFC, FCB thickness | 0.30mm, 0.33mm | 0.33mm | 0.33mm | 0.33mm | 0.33mm | 0.33mm |
| Locking feature | Slide Lock | - | - | - | Slide Lock | - |
| Positions | 2 | 4 | 5 | 6 | 6 | 9 |
| Termination | Solder | IDC | IDC | IDC | Solder | IDC |
Request a quote on any Amphenol 658011 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
