How do the Amphenol 69273 Series variants differ?

Amphenol 69273 Series part numbers differ by contact length - post, current rating, insulation color and operating temperature. Use the selection guide above to pick by contact length - post.

How many Amphenol 69273 Series part numbers are listed?

4 Amphenol 69273 Series part numbers are listed, each with specifications and a datasheet where available.

Amphenol 69273 Series

4 variants · Amphenol

About the Amphenol 69273 Series

The Amphenol 69273 Series series groups 4 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common applications of -, connector type of Header and contact finish - mating of Gold or Gold, GXT™. Variants differ by contact length - post, current rating and insulation color, so you can match the exact contact length - post your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current Amphenol 69273 Series variants and discontinued ones from a single page.

Select a variant by

Contact length - post: 0.110\" (2.79mm) · 0.150\" (3.81mm)
Current rating: - · 2.5A
Insulation color: Black · White
Operating temperature: - · -40°C~85°C
Voltage rating: - · 250VDC

Shared specifications

Applications: -
Connector type: Header
Contact finish - mating: Gold or Gold, GXT™
Contact finish - post: -
Contact finish thickness - mating: 30.0µin (0.76µm)
Contact finish thickness - post: -
Contact length - mating: -
Contact material: Copper Alloy
Contact shape: Square
Fastening type: Latch Holder
Features: Board Guide, Ground Pin
Gender: Male Pin

Variant comparison

Parameter	69273-104LF	69273-002LF	69273-102	69273-102LF
Contact length - post	0.110\" (2.79mm)	0.150\" (3.81mm)	0.110\" (2.79mm)	0.110\" (2.79mm)
Current rating	2.5A	2.5A	-	2.5A
Insulation color	Black	White	White	White
Operating temperature	-40°C~85°C	-40°C~85°C	-	-40°C~85°C
Voltage rating	250VDC	250VDC	-	250VDC

Request a quote on any Amphenol 69273 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.

Frequently asked questions

How do the Amphenol 69273 Series variants differ?: Amphenol 69273 Series part numbers differ by contact length - post, current rating, insulation color and operating temperature. Use the selection guide above to pick by contact length - post.
How many Amphenol 69273 Series part numbers are listed?: 4 Amphenol 69273 Series part numbers are listed, each with specifications and a datasheet where available.
How do I get pricing and lead time for Amphenol 69273 Series?: Request a quote (RFQ) for any Amphenol 69273 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
