91930-21109LF
Amphenol
9Tube0.039\" (1.00mm)
Ref. price$2.55
Lead time on requestGet quote ›
Amphenol 91930 Series
11 variants · Amphenol
About the Amphenol 91930 Series
The Amphenol 91930 Series series groups 11 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common connector type of Receptacle, Outer Shroud Contacts, contact finish of Gold or Gold, GXT™ and features of Board Guide, Solder Retention. Variants differ by contact finish thickness, package and positions, so you can match the exact contact finish thickness your application requires using the selection guide below. All listed Amphenol 91930 Series part numbers are active and orderable.
Select a variant by
- Contact finish thickness
- 15.0µin (0.38µm) · 30.0µin (0.76µm)
- Package
- Tape & Reel (TR); Cut Tape (CT) · Tube
- Positions
- 9 · 11 · 15 · 21 · 25 · 31 · 41 · 51 · 69
Shared specifications
- Connector type
- Receptacle, Outer Shroud Contacts
- Contact finish
- Gold or Gold, GXT™
- Features
- Board Guide, Solder Retention
- Height above board
- 0.129\" (3.28mm)
- Mated stacking heights
- 4.15mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 7.52mm
- Mounting type
- Surface Mount
- Pitch
- 0.039\" (1.00mm)
- Rows
- 2
Variant comparison
| Parameter | 91930-21109LF | 91930-21111LF | 91930-21115LF | 91930-21121LF | 91930-21125LF | 91930-21131LF |
|---|---|---|---|---|---|---|
| Contact finish thickness | 15.0µin (0.38µm) | 15.0µin (0.38µm) | 15.0µin (0.38µm) | 15.0µin (0.38µm) | 15.0µin (0.38µm) | 15.0µin (0.38µm) |
| Package | Tube | Tube | Tube | Tube | Tube | Tube |
| Positions | 9 | 11 | 15 | 21 | 25 | 31 |
Request a quote on any Amphenol 91930 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Amphenol 91930 Series variants differ?
- Amphenol 91930 Series part numbers differ by contact finish thickness, package and positions. Use the selection guide above to pick by contact finish thickness.
- How many Amphenol 91930 Series part numbers are listed?
- 11 Amphenol 91930 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Amphenol 91930 Series?
- Request a quote (RFQ) for any Amphenol 91930 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
