A85049124S11W
Amphenol
Cable ClampClamp Screws, Self-LockingOlive Drab
Ref. price$41.2
Lead time on requestGet quote ›
Amphenol A85049 Series
94 variants · Amphenol
About the Amphenol A85049 Series
The Amphenol A85049 Series series groups 94 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common cable exit of 180°, material of Aluminum Alloy and package of Bag. Variants differ by color, features and for use with (Related products), so you can match the exact color your application requires using the selection guide below.
Select a variant by
- Color
- Olive Drab · Silver
- Features
- Clamp Screws · Clamp Screws, Self-Locking · Self Locking
- For use with (Related products)
- MIL-DTL-38999 Series I, II · MIL-DTL-38999 Series III, IV
- Plating
- Cadmium · Electroless Nickel
- Shell size - insert
- 9, A · 11, B · 15, D · 17, E · 21, G · 24, 25 · 25, J
- Shielding
- Shielded · Unshielded
- Type
- Backshell, Cable Clamp · Backshell, E Nut · Cable Clamp
- Cable opening
- 0.130\" ~ 0.250\" (3.30mm ~ 6.35mm) · 0.260\" (6.60mm) · 0.380\" ~ 0.500\" (9.65mm ~ 12.70mm) · 0.460\" (11.68mm) · 0.550\" (13.97mm) · 0.630\" ~ 0.750\" (16.00mm ~ 19.05mm) · 0.690\" (17.53mm) · 0.850\" (21.59mm)
Shared specifications
- Cable exit
- 180°
- Material
- Aluminum Alloy
- Package
- Bag
- Primary material
- Metal
Variant comparison
| Parameter | A85049124S11W | A85049124S15W | A85049124S17W | A85049124S21N | A85049124S25W | A8504914S17W |
|---|---|---|---|---|---|---|
| Color | Olive Drab | Olive Drab | Olive Drab | Silver | Olive Drab | Olive Drab |
| Features | Clamp Screws, Self-Locking | Clamp Screws, Self-Locking | Clamp Screws, Self-Locking | Clamp Screws, Self-Locking | Clamp Screws, Self-Locking | Self Locking |
| For use with (Related products) | MIL-DTL-38999 Series III, IV | MIL-DTL-38999 Series III, IV | MIL-DTL-38999 Series III, IV | MIL-DTL-38999 Series III, IV | MIL-DTL-38999 Series III, IV | MIL-DTL-38999 Series III, IV |
| Plating | Cadmium | Cadmium | Cadmium | Electroless Nickel | Cadmium | Cadmium |
| Shell size - insert | 11, B | 15, D | 17, E | 21, G | 25, J | 17, E |
| Shielding | Shielded | Shielded | Shielded | Shielded | Shielded | Unshielded |
| Type | Cable Clamp | Cable Clamp | Cable Clamp | Cable Clamp | Cable Clamp | Backshell, E Nut |
| Cable opening | 0.260\" (6.60mm) | 0.460\" (11.68mm) | 0.550\" (13.97mm) | 0.690\" (17.53mm) | 0.850\" (21.59mm) | — |
Request a quote on any Amphenol A85049 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Amphenol A85049 Series variants differ?
- Amphenol A85049 Series part numbers differ by color, features, for use with (Related products) and plating. Use the selection guide above to pick by color.
- How many Amphenol A85049 Series part numbers are listed?
- 94 Amphenol A85049 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Amphenol A85049 Series?
- Request a quote (RFQ) for any Amphenol A85049 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
