ELFB05280
Amphenol
5Header, Female SocketsBlack
Ref. price$2.5900
Lead time on requestGet quote
Amphenol ELFB Header Plugs Sockets Series
2 variants · AmphenolAll Header Plugs & Sockets →
About the Amphenol ELFB Header Plugs Sockets Series
The Amphenol ELFB Header Plugs Sockets Series series groups 2 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common color of Black, contact material of Phosphor Bronze and contact mating finish of Tin. Variants differ by contact tail length, header orientation and insulation height, so you can match the exact contact tail length your application requires using the selection guide below. All listed Amphenol ELFB Header Plugs Sockets Series part numbers are active and orderable.
Select a variant by
- Contact tail length
- 0.123\" (3.12mm) · 0.138\" (3.50mm)
- Header orientation
- 90°, Right Angle · Vertical
- Insulation height
- 0.391\" (9.93mm) · 0.750\" (19.05mm)
- Positions
- 5 · 6
- Positions per level
- 5 · 6
Shared specifications
- Color
- Black
- Contact material
- Phosphor Bronze
- Contact mating finish
- Tin
- Current - IEC
- -
- Current - UL
- 15 A
- Features
- Interlocking (Side), Retention Latches
- Housing material
- Polyamide (PA46), Nylon 4/6
- IP rating
- -
- Material flammability rating
- UL94 V-0
- Mounting
- Through Hole
- Number of levels
- 1
- Operating temperature
- 125°C
Variant comparison
| Parameter | ELFB05280 | ELFB06230 |
|---|---|---|
| Contact tail length | 0.138\" (3.50mm) | 0.123\" (3.12mm) |
| Header orientation | Vertical | 90°, Right Angle |
| Insulation height | 0.750\" (19.05mm) | 0.391\" (9.93mm) |
| Positions | 5 | 6 |
| Positions per level | 5 | 6 |
Request a quote on any Amphenol ELFB Header Plugs Sockets Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
