M85049/1712W03
Amphenol
Clamp ScrewsCadmiumOlive Drab
Ref. price$57.84
Lead time on requestGet quote ›
Amphenol M85049 Series
76 variants · Amphenol
About the Amphenol M85049 Series
The Amphenol M85049 Series series groups 76 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common package of Bulk. Variants differ by cable exit, color and material, so you can match the exact cable exit your application requires using the selection guide below.
Select a variant by
- Cable exit
- 90° · 180°
- Color
- Black · Olive · Olive Drab · Silver · Yellow
- Material
- Aluminum · Aluminum Alloy · Metal, Steel
- Plating
- Anodized · Cadmium · Cadmium Nickel · Electroless Nickel · Yellow Chromate over Cadmium
- For use with (Related products)
- MIL-DTL-26482 Series II, MIL-DTL-5015 Series 3400, MIL-DTL-83723 Series I, III · MIL-DTL-26482 Series II, MIL-DTL-5015, MIL-DTL-83723 Series III · MIL-DTL-27599, MIL-DTL-38999 Series I, II · MIL-DTL-38999 Series I, II · MIL-DTL-38999 Series III, IV
- Shell size - insert
- 8 · 10 · 12, 13 · 13 · 14 · 15 · 18 · 25 · 25, J
- Type
- Backshell, Cable Clamp · Backshell, Heat Shrink Adapter · Cable Clamp
- Features
- Clamp Screws · Rotatable · Strain Relief
Shared specifications
- Package
- Bulk
Variant comparison
| Parameter | M85049/1712W03 | M85049/1813W03 | M85049/38-15A | M85049/38-25A | M85049/38-25W | M85049/39-25W |
|---|---|---|---|---|---|---|
| Cable exit | 180° | 180° | 180° | 180° | 180° | 90° |
| Color | Olive Drab | Olive | Black | Black | Olive | Olive |
| Material | Aluminum Alloy | Aluminum | Aluminum Alloy | Aluminum Alloy | Aluminum Alloy | Aluminum Alloy |
| Plating | Cadmium | Cadmium Nickel | Anodized | Anodized | Cadmium Nickel | Cadmium |
| For use with (Related products) | MIL-DTL-38999 Series I, II | MIL-DTL-38999 Series III, IV | MIL-DTL-38999 Series III, IV | MIL-DTL-38999 Series III, IV | MIL-DTL-38999 Series III, IV | MIL-DTL-38999 Series III, IV |
| Shell size - insert | 12, 13 | 13 | 15 | 25, J | 25 | 25, J |
| Type | Backshell, Cable Clamp | Backshell, Cable Clamp | Cable Clamp | Cable Clamp | Cable Clamp | Cable Clamp |
| Features | Clamp Screws | Clamp Screws | Clamp Screws | Strain Relief | Clamp Screws | Clamp Screws |
Request a quote on any Amphenol M85049 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Amphenol M85049 Series variants differ?
- Amphenol M85049 Series part numbers differ by cable exit, color, material and plating. Use the selection guide above to pick by cable exit.
- How many Amphenol M85049 Series part numbers are listed?
- 76 Amphenol M85049 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Amphenol M85049 Series?
- Request a quote (RFQ) for any Amphenol M85049 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
