RT07103W3PNH
Amphenol
64 pcs - 1 Connector, 1 Gasket, 1 Nut, 1 O-Ring-40°C ~ 105°C
Ref. price$18.09
Lead time on requestGet quote ›
Amphenol RT071 Series
21 variants · Amphenol
About the Amphenol RT071 Series
The Amphenol RT071 Series series groups 21 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common fastening type of Bayonet Lock, ingress protection of IP67 - Dust Tight, Waterproof and mounting feature of Bulkhead - Front Side Nut. Variants differ by connector type, operating temperature and package, so you can match the exact connector type your application requires using the selection guide below. All listed Amphenol RT071 Series part numbers are active and orderable.
Select a variant by
- Connector type
- Receptacle Housing · Receptacle, Female Sockets
- Operating temperature
- -40°C ~ 105°C · -40°C ~ 125°C
- Package
- Bag · Bulk
- Positions
- 4 · 6 · 8 · 12
- Shell material
- Zinc Alloy · Zinc Die Cast
- Shell size - insert
- 10-3W3 · 10-4 · 12-4 · 12-8 · 14-12
- Contact size
- 16 · 16 (3), 20 (3)
- Type
- For Female Sockets · For Male Pins
Shared specifications
- Fastening type
- Bayonet Lock
- Ingress protection
- IP67 - Dust Tight, Waterproof
- Mounting feature
- Bulkhead - Front Side Nut
- Mounting type
- Panel Mount
- Orientation
- N (Normal)
- Shell finish
- Nickel
Variant comparison
| Parameter | RT07103W3PNH | RT07103W3PNH03 | RT07103W3SNH | RT07103W3SNH03 | RT07104SNH | RT07124PNHEC03R |
|---|---|---|---|---|---|---|
| Connector type | Receptacle Housing | Receptacle Housing | Receptacle Housing | Receptacle Housing | Receptacle Housing | Receptacle Housing |
| Operating temperature | -40°C ~ 105°C | -40°C ~ 125°C | -40°C ~ 105°C | -40°C ~ 125°C | -40°C ~ 105°C | -40°C ~ 125°C |
| Package | Bag | Bag | Bag | Bag | Bulk | Bag |
| Positions | 6 | 6 | 6 | 6 | 4 | 4 |
| Shell material | Zinc Alloy | Zinc Alloy | Zinc Alloy | Zinc Alloy | Zinc Alloy | Zinc Alloy |
| Shell size - insert | 10-3W3 | 10-3W3 | 10-3W3 | 10-3W3 | 10-4 | 12-4 |
| Contact size | 16 (3), 20 (3) | 16 (3), 20 (3) | 16 (3), 20 (3) | 16 (3), 20 (3) | 16 | 16 |
| Type | For Male Pins | For Male Pins | For Female Sockets | For Female Sockets | For Female Sockets | For Male Pins |
Request a quote on any Amphenol RT071 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Amphenol RT071 Series variants differ?
- Amphenol RT071 Series part numbers differ by connector type, operating temperature, package and positions. Use the selection guide above to pick by connector type.
- How many Amphenol RT071 Series part numbers are listed?
- 21 Amphenol RT071 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Amphenol RT071 Series?
- Request a quote (RFQ) for any Amphenol RT071 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
