A-HDF 15 A-KG/T
Assmann WSW Components
15-55°C ~ 105°C3
Ref. price$1.01
Lead time on requestGet quote ›
Assmann WSW Components AHDF Series
21 variants · Assmann WSW Components
About the Assmann WSW Components AHDF Series
The Assmann WSW Components AHDF Series series groups 21 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common color of Black, connector type of Receptacle, Female Sockets and contact finish of Gold. Variants differ by dielectric material, flange feature and mounting type, so you can match the exact dielectric material your application requires using the selection guide below. All listed Assmann WSW Components AHDF Series part numbers are active and orderable.
Select a variant by
- Dielectric material
- Acrylonitrile Butadiene Styrene (ABS) · Polyamide (PA), Nylon, Glass Filled · Polybutylene Terephthalate (PBT), Glass Filled
- Flange feature
- Board Side (4-40) · Cable Side, Male Jackscrew · Housing/Shell (Unthreaded) · Mating Side, Female Screwlock · Mating Side, Female Screwlock (4-40)
- Mounting type
- Free Hanging (In-Line) · Panel Mount, Through Hole, Right Angle · Through Hole
- Positions
- 15 · 26
- Shell size, connector layout
- 1 (DE, E) High Density · 2 (DA, A) High Density
- Termination
- Solder · Solder Cup
- Operating temperature
- -55°C ~ 105°C · -20°C ~ 60°C · -20°C ~ 85°C
- Voltage rating
- 250V · 250VAC
Shared specifications
- Color
- Black
- Connector type
- Receptacle, Female Sockets
- Contact finish
- Gold
- Contact material
- Copper Alloy
- Gender
- Signal
- Package
- Tray
- Rows
- 3
Variant comparison
| Parameter | A-HDF 15 A-KG/T | A-HDF15-HOOD-WP | A-HDF 15 PP/Z | A-HDF 15 PP/Z-UNC1 | A-HDF 15 PP/Z-UNC2 | A-HDF 15 PP/Z-UNC3 |
|---|---|---|---|---|---|---|
| Dielectric material | Polybutylene Terephthalate (PBT), Glass Filled | Acrylonitrile Butadiene Styrene (ABS) | Polybutylene Terephthalate (PBT), Glass Filled | Polybutylene Terephthalate (PBT), Glass Filled | Polybutylene Terephthalate (PBT), Glass Filled | Polybutylene Terephthalate (PBT), Glass Filled |
| Flange feature | Mating Side, Female Screwlock (4-40) | Cable Side, Male Jackscrew | Housing/Shell (Unthreaded) | Mating Side, Female Screwlock (4-40) | Board Side (4-40) | Board Side (4-40) |
| Mounting type | Panel Mount, Through Hole, Right Angle | Free Hanging (In-Line) | Through Hole | Through Hole | Through Hole | Through Hole |
| Positions | 15 | 15 | 15 | 15 | 15 | 15 |
| Shell size, connector layout | 1 (DE, E) High Density | 1 (DE, E) High Density | 1 (DE, E) High Density | 1 (DE, E) High Density | 1 (DE, E) High Density | 1 (DE, E) High Density |
| Termination | Solder | Solder Cup | Solder | Solder | Solder | Solder |
| Operating temperature | -55°C ~ 105°C | -20°C ~ 60°C | -20°C ~ 85°C | -55°C ~ 105°C | -55°C ~ 105°C | -55°C ~ 105°C |
| Voltage rating | 250V | — | 250V | 250VAC | 250VAC | 250VAC |
