Assmann WSW Components H3CCH Series

13 variants · Assmann WSW Components

About the Assmann WSW Components H3CCH Series

The Assmann WSW Components H3CCH Series series groups 13 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common cable termination of IDC, connector type of Socket to Socket and contact finish of Gold. Variants differ by color, length and positions, so you can match the exact color your application requires using the selection guide below. All listed Assmann WSW Components H3CCH Series part numbers are active and orderable.

Select a variant by

Color: Gray, Ribbon · Multiple, Ribbon
Length: 0.500' (152.40mm, 6.00\") · 1.50' (457.20mm) · 3.00' (914.40mm)
Positions: 10 · 14 · 16 · 20 · 24 · 26

Shared specifications

Cable termination: IDC
Connector type: Socket to Socket
Contact finish: Gold
Contact finish thickness: Flash
Features: Polarizing Key
Package: Bulk
Pitch - cable: 0.050\" (1.27mm)
Pitch - connector: 0.100\" (2.54mm)
Rows: 2
Shielding: Unshielded

Variant comparison

Parameter	H3CCH-1018G	H3CCH-1018M	H3CCH-1406G	H3CCH-1606G	H3CCH-1618G	H3CCH-2006G
Color	Gray, Ribbon	Multiple, Ribbon	Gray, Ribbon	Gray, Ribbon	Gray, Ribbon	Gray, Ribbon
Length	1.50' (457.20mm)	1.50' (457.20mm)	0.500' (152.40mm, 6.00\")	0.500' (152.40mm, 6.00\")	1.50' (457.20mm)	0.500' (152.40mm, 6.00\")
Positions	10	10	14	16	16	20

Request a quote on any Assmann WSW Components H3CCH Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
