125-0592-001
Cinch Connectivity Solutions Johnson
50 Ohms-65°C ~ 165°CBulk
Ref. price$15.5500
Lead time on requestGet quote ›
Cinch Connectivity Solutions Johnson 1250 Series
7 variants · Cinch Connectivity Solutions Johnson
About the Cinch Connectivity Solutions Johnson 1250 Series
The Cinch Connectivity Solutions Johnson 1250 Series series groups 7 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common body finish of Gold, center contact material of Beryllium Copper and center contact plating of Gold. Variants differ by body material, cable group and connector type, so you can match the exact body material your application requires using the selection guide below. All listed Cinch Connectivity Solutions Johnson 1250 Series part numbers are active and orderable.
Select a variant by
- Body material
- Beryllium Copper · Brass
- Cable group
- - · 0.047\" Semi Rigid
- Connector type
- Jack, Female Socket · Jack, Male Pin · Plug, Male Pin
- Contact termination
- - · Solder
- Features
- - · Full Detent
- Frequency - max
- 20 GHz · 26.5 GHz · 40 GHz
- Impedance
- 50 Ohms · 50Ohm
- Includes
- - · 3 pcs - 1 Connector, 1 Cable Stop, 1 Contact
Shared specifications
- Body finish
- Gold
- Center contact material
- Beryllium Copper
- Center contact plating
- Gold
- Dielectric material
- Polytetrafluoroethylene (PTFE)
- Fastening type
- Snap-On
- Housing color
- Gold
- Ingress protection
- -
- Mating cycles
- 100
- Mounting feature
- -
- Number of ports
- 1
- Shield termination
- Solder
Variant comparison
| Parameter | 125-0592-001 | 125-0701-201 | 125-0701-211 | 125-0701-231 | 125-0701-801 | 125-0701-811 |
|---|---|---|---|---|---|---|
| Body material | Beryllium Copper | Beryllium Copper | Brass | Beryllium Copper | Beryllium Copper | Beryllium Copper |
| Cable group | 0.047\" Semi Rigid | - | - | - | - | - |
| Connector type | Plug, Male Pin | Plug, Male Pin | Jack, Male Pin | Plug, Male Pin | Plug, Male Pin | Plug, Male Pin |
| Contact termination | - | Solder | Solder | Solder | Solder | Solder |
| Features | Full Detent | Full Detent | Full Detent | Full Detent | Full Detent | Full Detent |
| Frequency - max | 40 GHz | 40 GHz | 20 GHz | 26.5 GHz | 40 GHz | 26.5 GHz |
| Impedance | 50 Ohms | 50 Ohms | 50 Ohms | 50Ohm | 50Ohm | 50Ohm |
| Includes | 3 pcs - 1 Connector, 1 Cable Stop, 1 Contact | - | - | - | - | - |
Request a quote on any Cinch Connectivity Solutions Johnson 1250 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Cinch Connectivity Solutions Johnson 1250 Series variants differ?
- Cinch Connectivity Solutions Johnson 1250 Series part numbers differ by body material, cable group, connector type and contact termination. Use the selection guide above to pick by body material.
- How many Cinch Connectivity Solutions Johnson 1250 Series part numbers are listed?
- 7 Cinch Connectivity Solutions Johnson 1250 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Cinch Connectivity Solutions Johnson 1250 Series?
- Request a quote (RFQ) for any Cinch Connectivity Solutions Johnson 1250 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
