2002-1-2-20-30-BK
CNC Tech
Surface Mount, Right Angle; Through HoleTape & Reel (TR) Cut Tape (CT)Receptacle
Ref. price$3.2000
Lead time on requestGet quote
CNC Tech 2002 Series
2 variants · CNC Tech
About the CNC Tech 2002 Series
The CNC Tech 2002 Series series groups 2 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common connector type of HDMI - Micro, contact finish of Gold and current rating of 0.3A. Variants differ by features, mounting and package, so you can match the exact features your application requires using the selection guide below. All listed CNC Tech 2002 Series part numbers are active and orderable.
Select a variant by
- Features
- - · Solder Retention
- Mounting
- Surface Mount, Right Angle · Surface Mount, Right Angle; Through Hole
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
Shared specifications
- Connector type
- HDMI - Micro
- Contact finish
- Gold
- Current rating
- 0.3A
- Gender
- Receptacle
- Insulation color
- Black
- Material flammability rating
- UL94 V-0
- Mating cycles
- 5000
- Mounting feature
- Horizontal
- Number of ports
- 1
- Operating temperature
- -20°C ~ 85°C
- Positions
- 19
- Shell (Shielding material)
- Copper Alloy
Variant comparison
| Parameter | 2002-1-2-20-30-BK | 2002-1-2-40-30-BK |
|---|---|---|
| Features | - | Solder Retention |
| Mounting | Surface Mount, Right Angle; Through Hole | Surface Mount, Right Angle |
| Package | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) |
Request a quote on any CNC Tech 2002 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
