How do the Dinkle Corporation, USA DK4N Series variants differ?

Dinkle Corporation, USA DK4N Series part numbers differ by color, package, positions and stripping length. Use the selection guide above to pick by color.

Dinkle Corporation, USA DK4N Series

16 variants · Dinkle Corporation, USA

About the Dinkle Corporation, USA DK4N Series

The Dinkle Corporation, USA DK4N Series series groups 16 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common disconnect type of -, features of - and fuse type of -. Variants differ by color, package and positions, so you can match the exact color your application requires using the selection guide below. All listed Dinkle Corporation, USA DK4N Series part numbers are active and orderable.

Select a variant by

Color: Beige · Blue · Brown · Gray · Green · Green, Yellow · Red · White · Yellow
Package: Box · Bulk
Positions: 2 · 3 · 4
Stripping length: 8mm ~ 10mm · 9mm ~ 11mm
Type: Feed Through · Ground, Earth
Voltage - IEC: - · 800V · 1000V
Voltage - UL: - · 600V

Shared specifications

Disconnect type: -
Features: -
Fuse type: -
Material - insulation: Polyamide (PA), Nylon
Material flammability rating: UL94 V-0
Number of levels: 1
Terminal - width: 6.1mm
Termination style: Screw

Variant comparison

Parameter	DK4N	DK4N-BL	DK4N-BR	DK4N-GN	DK4N-LG	DK4N-PE
Color	Gray	Blue	Brown	Green	Green	Green, Yellow
Package	Box	Bulk	Bulk	Bulk	Bulk	Box
Positions	2	2	2	2	2	2
Stripping length	9mm ~ 11mm	9mm ~ 11mm	9mm ~ 11mm	9mm ~ 11mm	9mm ~ 11mm	8mm ~ 10mm
Type	Feed Through	Feed Through	Feed Through	Feed Through	Feed Through	Ground, Earth
Voltage - IEC	1000V	800V	800V	800V	800V	-
Voltage - UL	600V	600V	600V	600V	600V	-

Request a quote on any Dinkle Corporation, USA DK4N Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.

Frequently asked questions

How do the Dinkle Corporation, USA DK4N Series variants differ?: Dinkle Corporation, USA DK4N Series part numbers differ by color, package, positions and stripping length. Use the selection guide above to pick by color.
How many Dinkle Corporation, USA DK4N Series part numbers are listed?: 16 Dinkle Corporation, USA DK4N Series part numbers are listed, each with specifications and a datasheet where available.
How do I get pricing and lead time for Dinkle Corporation, USA DK4N Series?: Request a quote (RFQ) for any Dinkle Corporation, USA DK4N Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
