Harwin Inc. M80-5T10205M2-02-331-00-000
MPNM80-5T10205M2-02-331-00-000
Active
CONN HEADER VERT 4POS 2MM
$24.09Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesDatamate Mix-Tek
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Datamate Mix-Tek |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Threaded |
| Operating temperature | -55°C ~ 125°C |
| Insulation color | Black |
| Insulation height | 0.220\" (5.60mm) |
| Insulation material | Polyphenylene Sulfide (PPS), Glass Filled |
| Mated stacking heights | 7.3mm, 9.75mm |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
All specifications
| Parameter | Value |
|---|---|
| Package | Bag |
| Features | Keying Slot, Mating Flange, Mounting Flange, Mounting Hardware |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Contact shape | Circular |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 4 (2 + 2 Power) |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact length - post | 0.130\" (3.30mm) |
| Contact finish - mating | Gold |
