The Molex 0015291027 is a 2-position closed top shunt from the C-Grid 7859 series, designed to jumper adjacent pins on a 0.100" (2.54mm) pitch header. This is the standard spacing for legacy and current C-Grid and KK interconnect systems, making the shunt a direct fit for those header rows. The closed top profile — a solid insulating cover — protects the contact beam from accidental shorting and debris ingress, a common requirement in unshrouded header applications where the shunt sits exposed on a board. Rated 5A per circuit, the shunt carries enough current for most logic-level and low-power jumper duties — configuration straps, address selection, enable lines. The 2-position grid (1 x 2) means it bridges exactly one pair of adjacent header pins. It mates with 0.025" (0.64mm) square pins on a 0.100" pitch — the industry-standard C-Grid and KK header pin. The black colour and 0.347" (8.81mm) height are consistent with the 7859 series visual and dimensional profile; no other colour variant is listed for this order code.

Molex C-Grid 7859 0015291027 Shunt, Closed Top, 2-Pos, Gold
MPN 0015291027
Active
Molex C-Grid 7859 series, 0015291027, Closed Top Shunt, 2 positions, 0.100" (2.54mm) pitch, Female Sockets, Gold 30.0µin contact finish, rated 5A, Black housing, UL94 V-0.
$0.7600
Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
RoHSROHS3 Compliant
IncotermsDAP / DDP Available
SeriesC-Grid 7859
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Type | Closed Top |
| Series | C-Grid 7859 |
| Current rating | 5A |
| Color | Black |
| Height | 0.347\" (8.81mm) |
| Housing material | Polyester, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Pitch | 0.100\" (2.54mm) |
| Gender | Female Sockets |
| Package | Bulk |
| Contact finish | Gold |
| Contact finish thickness | 30.0µin (0.76µm) |
| Number of positions or pins | 2 (1 x 2) |
