0348258201 Molex Mini50 34825 Header, 20-Pos, 2.00mm Pitch, Tin-Plated
MPN0348258201
Active
Molex Mini50 34825 header, 20 positions 2-row, 2.00 mm pitch, tin-plated brass contacts, 4-wall shrouded, latch holder, through-hole mount, UL94 V-0, gray SPS glass-filled housing, tape & reel.
$2.7702Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Mini50 34825 |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Latch Holder |
| Contact material | Brass |
| Insulation color | Gray |
| Insulation height | 0.614\" (15.60mm) |
| Insulation material | Syndiotactic Polystyrene (SPS), Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Features | Board Guide, Solder Retention |
All specifications
| Parameter | Value |
|---|---|
| Package | Tape & Reel (TR) |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 20 |
| Contact finish - post | Tin |
| Contact length - post | 0.113\" (2.87mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.218\" (5.55mm) |
Frequently asked questions
Where can I buy 0348258201 and what is the lead time?
Sourced and quoted to order against the BOM quantity through independent distribution; availability and current pricing are confirmed at quote time with no stock-holding claim made on this page.
What is 0348258201's connector style?
The 0348258201 is listed as Board to Cable/Wire style — a male pin header intended for through-hole board mount with the wire-side receptacle completing the harness path.
What series does the 0348258201 belong to?
It is a member of the Molex Mini50 34825 series — a 2.00 mm pitch automotive-grade header family with 4-wall shrouding and latch-holder retention.
