20-position shrouded header for wire-to-board power
The 0395011020 is the 20-circuit member of the Eurostyle ESE 39501 shrouded male pin header line, rated 8 A per contact at 300 V with a tin mating finish.
0395011020 Eurostyle ESE 20-Pin Header, 3.50mm, Active
MPN0395011020
Active
Eurostyle ESE 39501 header, order code 0395011020, 20 positions, single level, 0.138" (3.50mm) pitch, 8 A, 300 V, tin-plated mating contacts, through-hole vertical, solder termination.
$3.0431Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Type | Header, Male Pins, Shrouded (4 Side) |
| Series | Eurostyle ESE 39501 |
| Mounting | Through Hole |
| Voltage - UL | 300 V |
| Current - UL | 8 A |
| Operating temperature | -40°C ~ 105°C |
| Color | Black |
| Contact material | Brass |
| Housing material | Polyamide (PA66), Nylon 6/6 |
| Insulation height | 0.360\" (9.14mm) |
| Material flammability rating | UL94 V-0 |
| Pitch | 0.138\" (3.50mm) |
All specifications
| Parameter | Value |
|---|---|
| Package | Bulk |
| Number of levels | 1 |
| Termination style | Solder |
| Header orientation | Vertical |
| Contact tail length | 0.140\" (3.56mm) |
| Positions | 20 |
| Positions per level | 20 |
| Contact mating finish | Tin |
