Board-to-Wire Power Distribution Header
The 0395066006: The shrouded housing with a mating flange provides keyed alignment and prevents mismating with non-shrouded headers.
The right-angle orientation means the header sits flush to the board edge, with the pins extending perpendicular to the PCB plane. The mating flange accepts a corresponding screw-lock or latch on the receptacle side, providing vibration-resistant retention. The tin contact finish is rated for standard mating cycles — in a field-service application cycled quarterly, the interface will outlast the equipment service life without fretting corrosion.
Compliance and Material Notes
The green color is a visual identifier for the Eurostyle ESE series, aiding harness assembly verification. The single-level, 6-position layout matches standard terminal block receptacles in the Eurostyle ESE 39506 family.
