Right-angle shrouded header, 9 positions
The 0395066009 is the 9-circuit member of Molex's Eurostyle ESE 39506 shrouded header line, mounted through-hole with a right-angle orientation for board-edge wire-to-board connections.
Molex 0395066009 Eurostyle ESE 39506 Header, 9-Pos 3.50mm
MPN0395066009
Active
Molex Eurostyle ESE 39506 header, order code 0395066009, 9 positions, single level, 0.138" (3.50mm) pitch, 8 A, 300 V, tin-plated mating contacts, through-hole right-angle, solder termination.
$1.4651Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Type | Header, Male Pins, Shrouded (4 Side) |
| Series | Eurostyle ESE 39506 |
| Mounting | Through Hole |
| Voltage - UL | 300 V |
| Current - UL | 8 A |
| Operating temperature | -40°C ~ 105°C |
| Color | Green |
| Contact material | Brass |
| Housing material | Polyamide (PA66), Nylon 6/6 |
| Insulation height | 0.270\" (6.86mm) |
| Material flammability rating | UL94 V-0 |
| Pitch | 0.138\" (3.50mm) |
All specifications
| Parameter | Value |
|---|---|
| Features | Mating Flange |
| Package | Bulk |
| Manufacturer | Molex |
| Number of levels | 1 |
| Termination style | Solder |
| Header orientation | 90°, Right Angle |
| Contact tail length | 0.138\" (3.50mm) |
| Positions | 9 |
| Positions per level | 9 |
| Contact mating finish | Tin |
Product details
Frequently asked questions
What compliance documentation does Molex provide for the 0395066009?
RoHS and REACH compliance documentation is available from Molex for this part number.
