Eurostyle 39860 10-position plug
The 0398600110 is the 10-position member of Molex's Eurostyle 39860 plug line, a single-level screw-clamp terminal block plug for free-hanging in-line termination.
0398600110 Molex Eurostyle 39860 Plug, 10-Position, 5.08mm
MPN0398600110
Obsolete
Molex Eurostyle 39860 plug, order code 0398600110, 10 positions, single level, 0.200" (5.08mm) pitch, 15 A at 300 V UL, tin-plated phosphor bronze contacts, screw rising cage clamp termination, free-hanging in-line mount, black thermoplastic housing.
$4.9900Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Type | Plug, Female Sockets |
| Series | Eurostyle 39860 |
| Mounting | Free Hanging (In-Line) |
| Voltage - UL | 300 V |
| Current - UL | 15 A |
| Plug wire entry | 180° |
| Wire gauge or range - AWG | 12-26 AWG |
| Operating temperature | 110°C |
| Color | Black |
| Contact material | Phosphor Bronze |
| Housing material | Thermoplastic |
| Insulation height | 0.591\" (15.00mm) |
All specifications
| Parameter | Value |
|---|---|
| Pitch | 0.200\" (5.08mm) |
| Package | Bulk |
| Features | Retention Latches (Non-Wire Side) |
| Screw size | M3 |
| Number of levels | 1 |
| Termination style | Screw - Rising Cage Clamp |
| Positions | 10 |
| Positions per level | 10 |
| Contact mating finish | Tin |
Product details
Frequently asked questions
What is the connector type and termination style of the 0398600110?
It is a plug with female sockets, terminated by a screw rising cage clamp. The housing is free-hanging (in-line) with a 180° wire entry.
