Molex KK396 0416720005 Header, 6-Pos 3.96mm

MPN0416720005
Active

Molex KK396, 41672 header, order code 0416720005, 6 positions, single row, 3.96 mm pitch, gold-plated mating contacts, through-hole right-angle, solder termination.

$1.3317Ref. price · indicative, final on quote
0416720005 datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

0416720005 Technical Specifications
ParameterValue
SeriesKK396, 41672
GenderMale Pin
Mounting typeThrough Hole, Right Angle
Connector typeHeader, Breakaway
Fastening typeFriction Lock
Contact materialBrass
Insulation colorBlack
Insulation height0.355\" (9.02mm)
Insulation materialPolyester
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageBulk
ShroudingShrouded - 1 Wall
TerminationSolder
ApplicationsAutomotive, General Purpose, Industrial, Medical, Telecommunications
Contact shapeSquare
Rows1
Pitch0.156\" (3.96mm)
Positions6
Contact finish - postTin
Contact length - post0.212\" (5.38mm)
Contact finish - matingGold
Contact length - mating0.450\" (11.43mm)
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating15.0µin (0.38µm)

Product details

Board-to-board or cable header, shrouded one wall

The 0416720005 is the 6-circuit member of Molex's KK396, 41672 header line, a shrouded single-wall breakaway header for board-to-board or cable connections. It carries gold-plated mating contacts on a 3.96 mm pitch, mounts through-hole right-angle, and secures with a friction lock.

Housing material and flammability rating

The black polyester insulation is rated UL94 V-0 and stands 0.355" (9.02 mm) above the board. Applications include automotive, general purpose, industrial, medical, and telecommunications equipment.

Frequently asked questions

What is the 0416720005's listed style?

The style is Board to Board or Cable.

What series does the 0416720005 belong to?

The series is KK396, 41672.

What compliance documentation does Molex provide for the 0416720005?

RoHS and REACH compliance documentation is available from the manufacturer.
