Molex Mini-Fit BMI SMC 44068 series header, 0440680004, 10-position, 4.20mm pitch, shrouded 4-wall, through-hole, tin-plated contacts, UL94 V-0, tray.
| Parameter | Value |
|---|---|
| Series | Mini-Fit BMI SMC 44068 |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Latch Holder |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.587\" (14.91mm) |
| Insulation material | Polyamide (PA46), Nylon 4/6 |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Tray |
| Parameter | Value |
|---|---|
| Features | Blind Mating, Board Lock |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose, Industrial, Medical, Telecommunications |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.165\" (4.20mm) |
| Positions | 10 |
| Row spacing - mating | 0.165\" (4.20mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.193\" (4.90mm) |
| Contact finish - mating | Tin |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
The 0440680004: Blind mating capability means the header can be mated without direct line of sight — useful when the connector is recessed in a panel or behind other components.
ROHS3 compliant per the current revision, with no known obsolescence risk in the near term.
No stock-holding claim — quoted per RFQ.
This header mates with a Mini-Fit BMI SMC receptacle housing (e.g., Molex 044069 series) using the standard 4.20mm pitch crimp terminals. The latch holder fastening type secures the pair against vibration.
