Molex 0469921020 — Connector Housings

Molex Mini-Fit Jr Versa 46992 0469921020

MPN0469921020
Active

Molex Mini-Fit Jr Versa 46992 series, 0469921020, 10-position receptacle housing, 4.20mm pitch, 2 rows, crimp termination, latch lock, free hanging, red, glow wire compliant, -40°C to 105°C.

$2.7400Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesMini-Fit Jr Versa 46992
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

0469921020 specifications
ParameterValue
SeriesMini-Fit Jr Versa 46992
TypeFemale Socket
MountingFree Hanging (In-Line)
Connector typeReceptacle
Fastening typeLatch Lock
Operating temperature-40°C ~ 105°C
ColorRed
Insulation materialPolyamide (PA66), Nylon 6/6
NoteContacts Not Included
Pitch0.165\" (4.20mm)
PackageBag
FeaturesGlow Wire Compliant
Row spacing0.165\" (4.20mm)
Rows2
Contact terminationCrimp
Positions10

Product details

The Molex 0469921020 is a 10-position receptacle housing from the Mini-Fit Jr Versa 46992 series, a 4.20mm-pitch wire-to-wire and wire-to-board interconnect family.

Contacts Are Ordered Separately — What You Need

You need the matching Mini-Fit Jr crimp terminal, a female socket that inserts into the 10 cavities. The terminal accepts 18-24 AWG wire and is ordered by its own Molex order code (e.g. 44476-1111 for tin-plated, or 44476-2111 for gold-plated, depending on current and cycle-life requirements). The 2-row, 4.20mm row spacing means the terminal insertion tool nests into the rear of the housing; a secondary TPA (terminal position assurance) retainer is available for the series if the application sees vibration.

This receptacle mates with any Mini-Fit Jr header in the same 4.20mm pitch, 10-circuit, 2-row configuration — for example, the 46992-1020 vertical header or the 46992-2020 right-angle header. No polarising key or centre wall — the housing is symmetrical, so the header's orientation determines the wire exit direction. For a sealed assembly, use the Mini-Fit Jr TPA retainer (sold separately) to lock each terminal in place.

Frequently asked questions

What are the compatible contacts for Molex 0469921020?

Without the correct terminals, the housing cannot be used; this directly impacts design and sourcing.

What is the price and availability of 0469921020?

Buyers need to know cost and stock to fill BOM lines and decide where to purchase.

Can 0469921020 be used as a replacement for 46992-1020?

Maintenance techs need to verify dimensional and functional compatibility when swapping parts.

Is Molex 0469921020 obsolete or end of life?

Brokers and procurement must ensure long-term availability; obsolete parts require alternate sourcing.

What is the color and keying of 0469921020?

Color aids visual identification in harness assembly; keying prevents mis-mating.

Does 0469921020 come with contacts included?

The fact that contacts are not included is a critical detail for bill of materials and order completeness.
