Harness-Side Housing for a 14-Circuit Power Interconnect
It uses a 0.165" (4.20mm) pitch, which provides ample creepage for the series' rated current levels while keeping the board footprint compact for a 14-circuit connector. Keying is provided by the housing's internal geometry and the locking ramp on the mating face. The snap-in panel mount feature allows the housing to be secured into a panel cutout without separate hardware, simplifying field installation or service replacement.
Contacts Are Ordered Separately — Choose the Right Terminal
For the Mini-Fit Jr series, the standard male crimp pin for the plug housing is the 44476-1112 (or its equivalents), which accepts 18-24 AWG wire. The terminal's tin or gold plating grade should match the mating half's contact plating for galvanic compatibility and rated mating cycle life.
The mating connector for this 0469931410 plug housing is a Mini-Fit Jr 46993 series receptacle header, typically a vertical or right-angle through-hole header with 0.165" (4.20mm) pitch in a 2-row, 14-position layout. The receptacle header's locking ramp feature engages with the plug's ramp to provide the audible lock. The panel cutout for the snap-in mount is specified in the series drawing — typically a rectangular opening sized for the housing's panel-retention barbs.
