Molex Mi II 53325 header, order code 0533251160, 11 positions, single row, 2.00 mm pitch, Board to Cable/Wire, shrouded 4-wall, detent lock, through-hole right-angle, kinked pin solder termination, tin-plated mating contacts.
| Parameter | Value |
|---|---|
| Series | Mi II 53325 |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Detent Lock |
| Contact material | Brass |
| Insulation color | Natural |
| Insulation height | 0.191\" (4.85mm) |
| Insulation material | Polybutylene Terephthalate (PBT), Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tray |
| Parameter | Value |
|---|---|
| Shrouding | Shrouded - 4 Wall |
| Termination | Kinked Pin, Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 11 |
| Contact finish - post | Tin |
| Contact length - post | 0.138\" (3.50mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.136\" (3.45mm) |
The 0533251160 is the 11-circuit member of Molex's Mi II 53325 single-row header line, a Board to Cable/Wire connector with a shrouded 4-wall design and a detent lock that provides a positive mating retention.
RoHS and REACH compliance documentation is available from Molex upon request.
