Molex Mi II 55460 header, order code 0554601272, 12 positions, single row, 2.00 mm pitch, tin-plated mating contacts, surface-mount, solder termination, shrouded 4-wall, detent lock.
| Parameter | Value |
|---|---|
| Series | Mi II 55460 |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Detent Lock |
| Contact material | Brass |
| Insulation color | Natural |
| Insulation height | 0.276\" (7.00mm) |
| Insulation material | Polyamide (PA), Nylon |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Parameter | Value |
|---|---|
| Features | Solder Retention |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 12 |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
The 0554601272 is the 12-position member of Molex's Mi II 55460 single-row shrouded header line. It mates board-to-board or cable with 2.00 mm pitch, tin-plated square pins, and surface-mount solder termination.
The 0554601272 mates with a compatible Mi II 55460 receptacle housing and crimp terminals. Confirm the mating half position count and pitch before ordering.
