Molex C-Grid 70280 0702800445 Header, 94-Pos 2.54mm

MPN0702800445
Active

Molex C-Grid 70280 header, breakaway, order code 0702800445, 94 positions, dual row, 0.100" (2.54 mm) pitch, tin-plated mating contacts, through-hole, solder termination.

$8.7000Ref. price · indicative, final on quote
0702800445 datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

0702800445 Technical Specifications
ParameterValue
SeriesC-Grid 70280
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader, Breakaway
Fastening typePush-Pull
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.090\" (2.29mm)
Insulation materialLiquid Crystal Polymer (LCP), Glass Filled
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageBulk
ShroudingUnshrouded
TerminationSolder
ApplicationsAutomotive, General Purpose, Lighting, Medical, Telecommunications
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions94
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact length - post0.107\" (2.71mm)
Overall contact length0.437\" (11.10mm)
Contact finish - matingTin
Contact length - mating0.240\" (6.10mm)
Contact finish thickness - mating150.0µin (3.81µm)

Product details

What fits this 94-position breakaway

The 0702800445 is the 94-circuit member of Molex's C-Grid 70280 breakaway header line, unshrouded with a push-pull fastening system. Dual-row layout at 0.100" (2.54 mm) pitch with tin-plated mating contacts and through-hole solder termination — mates with C-Grid receptacles using the same 2.54 mm pitch.

Materials and flammability rating

Housing is liquid crystal polymer (LCP), glass filled, rated UL94 V-0. Contacts are copper alloy with tin plating on both the mating surface and the solder post.

Frequently asked questions

What compliance documentation does Molex provide for 0702800445?

The housing carries a UL94 V-0 flammability rating. Contact Molex directly for RoHS and REACH declarations specific to this order code.
