Molex 0702871007 C-Grid 70287 Header, 18 Pos, 2.54mm

MPN0702871007
Active

Molex C-Grid 70287 header, breakaway, order code 0702871007, 18 positions, dual row, 0.100" (2.54mm) pitch, tin-plated mating contacts, through-hole, kinked pin solder termination.

$0.7599Ref. price · indicative, final on quote
0702871007 datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

0702871007 Technical Specifications
ParameterValue
SeriesC-Grid 70287
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader, Breakaway
Fastening typePush-Pull
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.090\" (2.29mm)
Insulation materialLiquid Crystal Polymer (LCP), Glass Filled
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageBulk
ShroudingUnshrouded
TerminationKinked Pin, Solder
ApplicationsAutomotive, General Purpose, Lighting, Medical, Telecommunications
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions18
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact length - post0.125\" (3.18mm)
Overall contact length0.455\" (11.56mm)
Contact finish - matingTin
Contact length - mating0.240\" (6.10mm)
Contact finish thickness - mating150.0µin (3.81µm)

Product details

0.100" pitch, 18-circuit breakaway header

The 0702871007: Tin-plated mating contacts (150.0µin thickness) and tin-plated posts suit general-purpose signal interconnect in automotive, lighting, medical, and telecommunications equipment.

Series & positions

Within the C-Grid 70287 series the 0702871007's 18 positions sit between the 16-position and 20-position siblings — the 0.100" pitch, dual-row footprint, and tin-plated contacts are shared across the series, so match the position count to circuit count.
