Molex 0702871246 C-Grid 70287 Header, 6-Pos 2.54mm

MPN0702871246
Active

Molex C-Grid 70287 header, order code 0702871246, 6 positions, dual row, 0.100" (2.54mm) pitch, gold-plated mating contacts, through-hole, kinked pin solder termination, bulk packaging.

$0.4900Ref. price · indicative, final on quote
0702871246 datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

0702871246 Technical Specifications
ParameterValue
SeriesC-Grid 70287
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader, Breakaway
Fastening typePush-Pull
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.090\" (2.29mm)
Insulation materialLiquid Crystal Polymer (LCP), Glass Filled
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageBulk
ShroudingUnshrouded
TerminationKinked Pin, Solder
ApplicationsAutomotive, General Purpose, Lighting, Medical, Telecommunications
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions6
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact length - post0.125\" (3.18mm)
Overall contact length0.535\" (13.59mm)
Contact finish - matingGold
Contact length - mating0.320\" (8.13mm)
Contact finish thickness - post74.8µin (1.90µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

6-position breakaway header, 2.54 mm pitch

The 0702871246 is the 6-circuit member of Molex's C-Grid 70287 breakaway header line, unshrouded with a push-pull fastening system. Gold-plated mating contacts (30.0 µin) suit repeated mating cycles; the through-hole mounting with kinked pins holds the header in place during wave solder.

Board-to-board or cable duty

Listed for Automotive, General Purpose, Lighting, Medical, and Telecommunications applications — the UL94 V-0 LCP housing and copper alloy contacts handle the thermal and vibration range common to those environments.
