Molex C-Grid 71308 header, breakaway, order code 0713085488, 88 positions, dual row, 0.100" (2.54 mm) pitch, tin-plated mating contacts, surface mount, solder termination.
Molex C-Grid 71308 header, breakaway, order code 0713085488, 88 positions, dual row, 0.100" (2.54 mm) pitch, tin-plated mating contacts, surface mount, solder termination.
$3.0812Ref. price · indicative, final on quote
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
- New & original stockTraceable channels only — no mixed lots, no re-taped reels.
- Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
- Photo-verified countsEvery line counted and photographed before the box closes.
- PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
Specifications
| Parameter | Value |
|---|---|
| Series | C-Grid 71308 |
| Gender | Male Pin |
| Mounting type | Surface Mount |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.090\" (2.29mm) |
| Insulation material | Liquid Crystal Polymer (LCP), Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Tube |
| Shrouding | Unshrouded |
| Termination | Solder |
| Applications | Automotive, General Purpose, Lighting, Medical, Telecommunications |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 88 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact length - mating | 0.240\" (6.10mm) |
| Contact finish thickness - post | 59.0µin (1.50µm) |
| Contact finish thickness - mating | 59.0µin (1.50µm) |
Product details
Frequently asked questions
What compliance documentation does Molex provide for 0713085488?
RoHS and REACH compliance documentation is available from Molex per the base product number 071308.
