Right-angle board-edge header, 4 circuits, 2.54 mm pitch
The breakaway design means this header is snapped from a longer strip; the 4-position length is factory-set and the tails are already cut to 0.110" post length for solder wave or hand-solder assembly.
Tin-plated contacts and UL94 V-0 housing
Board-to-board or cable interconnect
Listed as suitable for board-to-board or cable applications. When used as a board-to-board header, the 0.240" mating pin length provides clearance for a standard 0.100" pitch receptacle. For cable interconnect, it mates with C-Grid crimp housings that accept 22-28 AWG wire.
ROHS3 compliant.
