Molex SL 74099 header, order code 0740990009, 9 positions, single row, 0.100" (2.54mm) pitch, tin-plated mating contacts, shrouded - 4 wall, surface-mount, solder termination.
Molex SL 74099 0740990009 Header, 9-Pos 2.54mm
MPN0740990009
Active
Molex SL 74099 header, order code 0740990009, 9 positions, single row, 0.100" (2.54mm) pitch, tin-plated mating contacts, shrouded - 4 wall, surface-mount, solder termination.
$2.7300Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | SL 74099 |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Latch Holder |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.450\" (11.43mm) |
| Insulation material | Polyester, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tube |
All specifications
| Parameter | Value |
|---|---|
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Industrial, Medical |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 9 |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact length - mating | 0.240\" (6.10mm) |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 150.0µin (3.81µm) |
Product details
Frequently asked questions
What compliance documentation does Molex provide for the 0740990009?
RoHS and REACH compliance documentation is available from Molex upon request.
