Molex SL 74099 series, SMT header, 3 positions, single row, 0.100" (2.54 mm) pitch, shrouded 4-wall, tin-plated male pins, latch holder fastening, UL94 V-0, ROHS3 compliant.
| Parameter | Value |
|---|---|
| Series | SL 74099 |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Latch Holder |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.450\" (11.43mm) |
| Insulation material | Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Parameter | Value |
|---|---|
| Features | Pick and Place |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Industrial, Medical |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 3 |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact length - mating | 0.240\" (6.10mm) |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 150.0µin (3.81µm) |
The 0740990603: The 0.450" (11.43 mm) insulation height leaves clearance for components on the board under the header body.
The square male pins, 0.240" (6.10 mm) mating length, engage with the receptacle contacts for a reliable connection.
ROHS3 compliant per the manufacturer listing.
The 0740990603 mates with a SL series 3-circuit receptacle housing and matching crimp terminals. The single-row, 0.100" pitch layout requires a female counterpart with the same circuit count and pitch.
