Molex Pico-SPOX 87437 series, 0874370343, a 3-position single-row shrouded header, 1.50 mm pitch, surface-mount termination, tin-plated male pins, beige UL94 V-0 nylon housing, 7.4 mm mated stack height, board-to-cable/wire style.
| Parameter | Value |
|---|---|
| Series | Pico-SPOX 87437 |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Brass Alloy |
| Insulation color | Beige |
| Insulation height | 0.199\" (5.05mm) |
| Insulation material | Polyamide (PA), Nylon |
| Mated stacking heights | 7.4mm |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Parameter | Value |
|---|---|
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose, Medical |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.059\" (1.50mm) |
| Positions | 3 |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact length - mating | 0.106\" (2.70mm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
In a low-vibration environment (medical equipment, consumer electronics), this is adequate; in an automotive or industrial cabinet with constant shock, you'd want a locking feature or a TPA on the receptacle side. The brass alloy contacts with tin post finish are a standard cost-effective choice for non-corrosive, indoor applications.
This header mates with a Pico-SPOX receptacle housing (sold separately) that accepts the matching crimp terminals.
