15-Position SMD Header for Tight Board-to-Cable Routing
The 0874371543: This Molex Pico-SPOX 87437 header is a 15-position, single-row, surface-mount male pin header with a 1.50mm pitch. The 7.4mm mated stacking height keeps the overall board-to-cable profile low.
Board Layout Dimensions and Solder Termination
The surface-mount pads require a solder paste stencil designed for the 1.50mm pitch; no special mounting guidelines beyond standard SMD reflow profiles for nylon.
Tin-Plated Contacts: Cost-Effective for Moderate Cycling
This thick tin layer handles moderate mating cycles — typically 25 to 50 cycles — without exposing the brass alloy base.
It is ROHS3 compliant. The base product number is 87437; the full 15-position variant is 0874371543. No official successor or pin-compatible alternative is recorded from Molex, so the BOM line should be locked to this order code unless a cross-shop evaluation is performed.
