The 0877592250 is a 22-position, 2.00mm pitch unshrouded breakaway header from the Molex Milli-Grid 87759 series. The header mates with either a board-mounted receptacle or a crimp-housing cable assembly, giving the designer flexibility in the interconnect topology.
At 2.00mm pitch, this header occupies a compact footprint on the board — about 0.630" (16.00mm) total length for the 22-position version. The unshrouded design keeps the board-edge profile low: the insulation height is just 0.059" (1.50mm) above the board surface.
The part ships in a tube (package type: Tube).
Material and Compliance Notes
The header includes a board guide feature to assist alignment during assembly. It is RoHS compliant per Molex's standard declaration.
