Molex Milli-Grid 87759 header, order code 0877594084, 40 positions, dual row, 2.00 mm pitch, gold-plated mating contacts, surface-mount, unshrouded, solder termination.
| Parameter | Value |
|---|---|
| Series | Milli-Grid 87759 |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.059\" (1.50mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Tape & Reel (TR) |
| Parameter | Value |
|---|---|
| Shrouding | Unshrouded |
| Termination | Solder |
| Applications | Automotive, General Purpose, Telecommunications |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 40 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Gold |
| Contact length - mating | 0.150\" (3.81mm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 0877594084 is the 40-circuit member of Molex's Milli-Grid 87759 header line, a dual-row unshrouded breakaway header on 2.00 mm pitch. Gold-plated mating contacts rated for signal-level current; the surface-mount solder termination fits automated assembly.
The header supports board-to-board or cable connections and is listed for automotive, general-purpose, and telecommunications equipment.
The mating pitch is 0.079" (2.00 mm) with 40 positions loaded in two rows.
