Molex 0879110611 — Pin Headers

Molex 0879110611 C-Grid 87911 Header – 6-Pin Right Angle

MPN0879110611
Active

Molex C-Grid 87911 series, 0879110611, 6-position unshrouded header, 2.54mm pitch, right-angle through-hole, gold-plated male pins, UL94 V-0 LCP housing.

$1.2000Ref. price · indicative, final on quote
Molex 0879110611 datasheet (PDF)
RoHSROHS3 Compliant
SeriesC-Grid 87911
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

0879110611 key specifications
ParameterValue
SeriesC-Grid 87911
TypeMale Pin
MountingThrough Hole, Right Angle
Connector typeHeader, Breakaway
Fastening typePush-Pull
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.196\" (4.98mm)
Insulation materialLiquid Crystal Polymer (LCP), Glass Filled
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageTube

All specifications

0879110611 additional specifications
ParameterValue
ShroudingUnshrouded
TerminationSolder
ApplicationsAutomotive, General Purpose, Lighting, Medical, Telecommunications
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions6
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact length - post0.125\" (3.18mm)
Contact finish - matingGold
Contact length - mating0.240\" (6.10mm)
Contact finish thickness - post74.8µin (1.90µm)
Contact finish thickness - mating15.0µin (0.38µm)

Product details

2.54mm pitch breakaway header – 6 positions, right-angle

The 0879110611 is a 6-position, dual-row breakaway header from Molex's C-Grid 87911 series. The 2.54mm pitch matches standard 0.100" grid patterns, so board layout is straightforward for prototyping or production runs. The 0.125" solder post length suits typical 1.6mm-thick boards.

Gold-plated mating surface for repeated connects

The post tails are tin-plated (74.8µin) for good solderability with standard lead-free processes.

Unshrouded push-pull design – mates with C-Grid receptacles

ROHS3 compliant.

Frequently asked questions

What are the specifications of Molex 0879110611?

The 0879110611 is a 6-position, dual-row, unshrouded breakaway header with 2.54mm pitch, right-angle through-hole mounting, gold-plated mating contacts (15.0µin), and tin-plated posts. It mates with C-Grid series receptacles and is rated for general-purpose, automotive, medical, and telecom applications.
