Molex C-Grid III 90130 series header, 0901301220, 20-position, 2.54mm pitch, shrouded 4-wall, through-hole, gold mating finish, latch holder, UL94 V-0, ROHS3 compliant, active production.
| Parameter | Value |
|---|---|
| Series | C-Grid III 90130 |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Latch Holder |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.429\" (10.90mm) |
| Insulation material | Polyester, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tray |
| Parameter | Value |
|---|---|
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 20 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.114\" (2.90mm) |
| Overall contact length | 0.510\" (12.95mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.266\" (6.75mm) |
| Contact finish thickness - post | 118.1µin (3.00µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 0901301220: This is a 20-position, 2-row, 0.100" (2.54mm) pitch shrouded header from the Molex C-Grid III 90130 series. It mates with the corresponding C-Grid III crimp receptacle housings (90119/90123 series) to create a board-to-cable/wire connection.
Sourced through independent distribution channels. Quoted to order against your BOM quantity; availability and current pricing confirmed at quote time. No stock-holding claim — every order is sourced per RFQ.
Yes — this header is part of the C-Grid III 90130 series and mates with the corresponding 90119/90123 series crimp receptacle housings. The 2.54mm pitch, 20-position, 2-row layout with latch holder is designed for that interface.
