Right-angle header for board-edge routing
The 0901303140: The 0.100-inch (2.54mm) pitch and matching row spacing set the PCB footprint and routing density — a standard grid that accommodates 40 signal or power lines in a compact dual-row layout. All positions are loaded, so no depopulation to manage.
Plating and contact design for moderate-duty cycles
The square male pins are made of brass, a common choice for good conductivity and solderability. The 0.266-inch (6.75mm) mating length provides sufficient engagement depth for reliable contact with the receptacle.
Shrouded housing and flammability rating
The insulation height of 0.384 inches (9.75mm) and black color are consistent with the C-Grid III series, aiding visual identification in dense harness assemblies.
