Right-Angle 16-Position Header for Board-to-Cable
The 0901303216: This is a 16-position, 2.54mm pitch header from the Molex C-Grid III 90130 series, configured as a right-angle through-hole mount for board-to-cable/wire applications.
Molex 0901303216 C-Grid III Header, 16-Pin, 2.54mm
MPN0901303216
Active
Molex C-Grid III 90130 series, 16-position, 2.54mm pitch, right-angle through-hole header, shrouded 4-wall, gold-plated male pins, latch holder, UL94 V-0.
$5.0800Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesC-Grid III 90130
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | C-Grid III 90130 |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Latch Holder |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.384\" (9.75mm) |
| Insulation material | Polyester, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tray |
All specifications
| Parameter | Value |
|---|---|
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 16 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.114\" (2.90mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.266\" (6.75mm) |
| Contact finish thickness - post | 118.1µin (3.00µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
Product details
Frequently asked questions
What does the 0901303216 mate with?
It mates with C-Grid III receptacle housings that accept 2.54mm pitch crimp terminals.
Is the 0901303216 shrouded?
Yes, it has a shrouded 4-wall housing that fully encloses the male pins, protecting them from damage and preventing mis-mating.
