Molex 0901310124 — Pin Headers

0901310124 Molex C-Grid III 90131 Header 8 Pos 2.54mm

MPN0901310124
Active

Molex C-Grid III 90131 series, 0901310124, board-to-cable/wire header, 8 positions, 2.54mm pitch, through hole, unshrouded, tin-plated contacts, UL94 V-0, Active

$0.9700Ref. price · indicative, final on quote
Molex 0901310124 datasheet (PDF)
RoHSROHS3 Compliant
SeriesC-Grid III 90131
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

0901310124 key specifications
ParameterValue
SeriesC-Grid III 90131
TypeMale Pin
MountingThrough Hole
Connector typeHeader, Breakaway
Fastening typePush-Pull
Contact materialBrass
Insulation colorBlack
Insulation height0.098\" (2.50mm)
Insulation materialPolyester, Glass Filled
Material flammability ratingUL94 V-0
StyleBoard to Cable/Wire
PackageBulk

All specifications

0901310124 additional specifications
ParameterValue
ShroudingUnshrouded
TerminationSolder
ApplicationsAutomotive, General Purpose
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions8
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact length - post0.114\" (2.90mm)
Overall contact length0.478\" (12.15mm)
Contact finish - matingTin
Contact length - mating0.266\" (6.75mm)
Contact finish thickness - post118.1µin (3.00µm)
Contact finish thickness - mating118.1µin (3.00µm)

Product details

8-Position Breakaway Header for C-Grid III 90131

The 0901310124: The tin-plated square pins mate with standard C-Grid III crimp receptacles—the same 2.54mm spacing used across the series for board-to-wire connections.

Tin Plating and Contact Finish

Tin works well for connections that are mated and left in place; it's not rated for frequent reconnects the way gold is.

Through-Hole Mounting and Board Fit

Material and Environmental Rating

The housing is glass-filled polyester rated UL94 V-0—it won't sustain a flame in an enclosed equipment scenario. The header is listed for automotive and general-purpose use, which covers a wide ambient temperature range typical of underhood or industrial cabinet environments. ROHS3 compliant per the current lifecycle status.

Frequently asked questions

What is the pitch and position count of 0901310124?

The pitch is 0.100" (2.54mm) with 8 positions arranged in two rows. Row spacing is also 0.100" (2.54mm).

Does 0901310124 have a locking feature?

No—the fastening type is push-pull, meaning the header is unshrouded and relies on friction fit with the mating receptacle. There is no latch or secondary lock.

What is the closest pin-compatible alternative to 0901310124 in the C-Grid III 90131 family?

Within the same series, the 090131 series includes other position counts at the same 2.54mm pitch.

Where can I buy 0901310124?

Availability and current pricing confirmed at quote time.
