Gold mating finish — 15.0µin on brass pins
The 0901310772: The post finish is tin (118.1µin, 3.00µm) for solderability. Square male pins (0.025" square typical for this series) mate with standard C-Grid III crimp receptacles.
0901310772 Molex C-Grid III 90131 Header 24POS 2.54mm
MPN0901310772
Active
Molex C-Grid III 90131 series, 0901310772: vertical unshrouded header, 24 positions, 2 rows, 0.100" (2.54mm) pitch, gold-plated brass pins, through-hole solder termination, UL94 V-0 black polyester housing.
$4.4700Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesC-Grid III 90131
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | C-Grid III 90131 |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.098\" (2.50mm) |
| Insulation material | Polyester, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Bulk |
All specifications
| Parameter | Value |
|---|---|
| Shrouding | Unshrouded |
| Termination | Solder |
| Applications | Automotive, General Purpose |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 24 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.114\" (2.90mm) |
| Overall contact length | 0.478\" (12.15mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.266\" (6.75mm) |
| Contact finish thickness - post | 118.1µin (3.00µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
Product details
Frequently asked questions
What is the mating connector for 0901310772?
This header mates with a C-Grid III crimp receptacle housing (e.g., 16-position or 24-position dual-row housings) loaded with the matching crimp terminals. The unshrouded pins accept standard 0.025" square female receptacles.
Is 0901310772 suitable for automotive applications?
Yes, the listed applications include automotive and general-purpose use. The UL94 V-0 housing and gold mating finish support the thermal and vibration demands of automotive environments.
