Molex C-Grid III 90131 header, order code 0901310799, 78 positions, dual row, 0.100" (2.54mm) pitch, gold-plated mating contacts, tin-plated solder tails, through-hole, solder termination, unshrouded, push-pull fastening.
| Parameter | Value |
|---|---|
| Series | C-Grid III 90131 |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.098\" (2.50mm) |
| Insulation material | Polyester, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tray |
| Parameter | Value |
|---|---|
| Shrouding | Unshrouded |
| Termination | Solder |
| Applications | Automotive, General Purpose |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 78 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.114\" (2.90mm) |
| Overall contact length | 0.478\" (12.15mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.266\" (6.75mm) |
| Contact finish thickness - post | 118.1µin (3.00µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 0901310799 is the 78-circuit member of Molex's C-Grid III 90131 breakaway header line, unshrouded with push-pull fastening. Through-hole solder termination, 0.100" (2.54mm) pitch, gold-over-brass mating contacts rated 3 A per circuit, tin-plated solder tails.
RoHS and REACH compliance documentation is available from Molex on request.
