Molex C-Grid III 90136 series, 0901361107, board-to-cable/wire header, 7 positions, single row, 0.100" (2.54mm) pitch, tin-plated male pins, through-hole, shrouded 4-wall, latch holder, UL94 V-0, ROHS3.
| Parameter | Value |
|---|---|
| Series | C-Grid III 90136 |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Latch Holder |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.429\" (10.90mm) |
| Insulation material | Polyester, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tray |
| Parameter | Value |
|---|---|
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 7 |
| Contact finish - post | Tin |
| Contact length - post | 0.114\" (2.90mm) |
| Overall contact length | 0.510\" (12.95mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.266\" (6.75mm) |
| Contact finish thickness - mating | 118.1µin (3.00µm) |
The 0901361107: The mating half is a C-Grid III receptacle housing (e.g., Molex 90119 series) that accepts the corresponding crimp terminals. Current rating for the tin-plated contact interface is typically 2.5 A per circuit at 25°C ambient — the tin finish limits the current ceiling compared to gold-plated variants in the same series. The insulation height of 0.429" (10.90mm) sets the z-height above the board — relevant for enclosure clearance.
The mating half is a C-Grid III receptacle housing from the 90119 series, 7-circuit, single-row, 0.100" pitch. It accepts the corresponding crimp terminals (e.g., Molex 90119-xxxx).
The tin-plated contact interface is typically rated 2.5 A per circuit at 25°C ambient. The tin finish limits the continuous current compared to gold-plated variants in the same series. Derate above 25°C per the product drawing.
