7-Pin Shrouded Header for Wire-to-Board Harnesses
The 0901361207: The post tails are tin-plated (118.1µin / 3.00µm) for reliable solder wetting in wave or hand-solder processes.
The 0.100" pitch keeps routing density manageable on two-layer boards.
Molex 0901361207 C-Grid III Header, 7 Pos, 2.54mm Pitch
MPN0901361207
Active
Molex C-Grid III 90136 series, 0901361207, board-to-cable/wire header, 7 positions, single row, 0.100" (2.54mm) pitch, through-hole solder termination, shrouded 4-wall, gold-plated mating contacts, latch holder fastening, UL94 V-0 housing.
$2.6500Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesC-Grid III 90136
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | C-Grid III 90136 |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Latch Holder |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.429\" (10.90mm) |
| Insulation material | Polyester, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tray |
All specifications
| Parameter | Value |
|---|---|
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 7 |
| Contact finish - post | Tin |
| Contact length - post | 0.114\" (2.90mm) |
| Overall contact length | 0.510\" (12.95mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.266\" (6.75mm) |
| Contact finish thickness - post | 118.1µin (3.00µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
